स्वचालित पंचिंग मशीन

Heidelberg Dymatrix 106 CSB pro

Machine for punching, embossing, waste removal, and blank separation
- as is -

System equipped with a high-performance sheet feeder designed for automatic NON-STOP operation
⦁ For fully automatic punching, creasing, and embossing with or without gripper edge
⦁ For removal of internal waste as well as lateral and rear sheet edges
⦁ For stack-like delivery of punched and waste-removed sheets with attached gripper edges or
⦁ For separation of gripper edges and subsequent stack-like delivery of the remaining sheets
⦁ With a patented gripper carriage registration system for highest registration accuracy
⦁ With a pile stacker machine enabling fully automatic interleaving sheet feed as well as NON-STOP stacking and does not require modification even for the smallest job sizes (exchange table with comb structure)
⦁ Interleaving sheet magazine with electronic level monitoring, refillable during production
⦁ With Centerline equipment
⦁ With automatic pallet change device at the delivery section

Nwsdpfjww E Nrsx Aazec
Specification
Maximum sheet size: 760 x 1060 mm
Minimum sheet size: 350 x 400 mm
Maximum punching force: 3.3 MN (330 t)
Speed: 9,000 sheets/hour

Processable materials:
Paper min. 80 g/m²
Cardboard up to 2000 g/m²
Corrugated board up to 3 mm
(max. sheet warp 4%)

Equipment:
Optical sheet register (Dyset)
Automatic non-stop feeder
Waste removal station
Blank separation station
Centerline
Fully automatic pallet changing device at delivery
Incl. platform
Quick-lock frames at all tooling stations
