डिजिटल प्रिंट मशीन

TICAB PRINT Printing System for packaging \ CMYK \

TITAN DOUBLE
Trade Industrial Company AB is a Polish manufacturer of modern professional equipment
trusted by professionals in over 55 countries worldwide. Industrial printer TITAN DOUBLE is designed for
inkjet large format contactless full-color CMYK printing.
OUR ADVANTAGES = YOUR BENEFITS:
TITAN DOUBLE
The new printing machine from TICAB PRINT has two print heads. Now, you can print in a single pass on large items. Your benefits:
• Enhanced workflows.
• Wider range or samples to print on.
• More comfort during printing.
We are official partners of the Hewlett Packard Company. You can get the TITAN DOUBLE printing machines at the manufacturer’s price. Online education and full technical support is provided.
KEY FEATURES of TITAN DOUBLE:
1) Average printing speed is 50 units per minute.
2) The opportunity to print from 1 copy without increased cost per piece.
3) No preparations or cliches are needed.
4) Low cost per copy is from 0.01 euro/unit (you will see an accurate amount on the monitor during
printing).
5) Printing on different materials: paper, carton (assembled and disassembled boxes), textile, wood,
and plywood.
6) Branded software from TICAB PRINT (included in the printer's price).
7) Printer's components and accessories of our own design and production.

TITAN DOUBLE is an innovative printing system. It allows you to feed huge items
beneath the printer head. Printer heads can be adjusted up to 10 cm above the conveyor
belt. High quality Hewlett Packard HP pigment ink provides resistance to the fading, scratches.
and water after the image dries.

Technical Characteristics of the Printer head:
Print area width - up to 59.4cm (23.4 in)
Print area length - from 2.54 cm (1 inch) to 91.44 cm (36 inch)
Workpiece movement speed - up to 45.72 cm (18 in) per second
Printing speed - up to 50 arc\ min A4, up to 16 arc\ min A3
Gjdpfx Aevt Uvzjg Iobg
Print resolution - 1200x1200dpi
Colors - CMYK (Cyan, Magenta, Yellow, Black)
Ink type - water-based pigment ink
Information connection - Ethernet 10/100/1000 Base-T network port
Operating system - Windows (recommended Windows10)
Hewlett Packard HP driver
TICAB software:
The current status of the printer is being monitored.
Number of prints is calculated - the total and the current task.
The calculation of the value of ink consumption.
Monitoring the current level of ink in the cartridges.
Starting the printer nozzle maintenance and cleaning functions.
Starting the procedures for replacing the cleaning mechanism.
Calibrate the printer nozzles for linearity and color uniformity.
Start the procedure for high-speed printing of a large number of copies.
