वाइड बेल्ट सैंडर

Bütfering Classic 213

Technical Main Data
- Grinding width: 1,350 mm
- Working height: 900 mm (constant)
Nledoxmwn Aspfx Adqjk
- Workpiece thickness: max. 150 mm
- Abrasive belt width: 1,370 mm
- Segment grinding shoe
- Weight: approx. 3,000 kg

Drives
1st unit: 15–18.5 kW, belt speed 18 m/s
2nd unit: 11–15 kW, belt speed 18 m/s
Contact roller diameter: 140 mm (combi unit)

Feed:
- Feed belt system: length 3,400 mm, width 1,350 mm
- Feed drive: 0.7/0.9 kW (2 speeds)
- Feed speed: infinitely variable, 2.5–13 m/min

Extraction
- Air velocity: min. 20 m/s
- Machine resistance: approx. 800 Pa

Compressed Air:
- Operating pressure: 6–8 bar
- Air consumption: approx. 28 l/min
